EPE Foam sheet Unit(FCFPM-150)

Place of Origin : Longkou ,Shandong Province, China

Brand Name : FC

Certification : CE/ISO9001

Model Number : FCFPM-150

Capacity(T/day) : 5T/day

MOQ : 1set or mail to lewis@goodeggtraymachine-com.ecer.com

Packaging Details : Export Standard Package

Delivery Time : Within 40-60 days

Payment Terms : T/T

Supply Ability : 100set/year

Plastic Processed : PE

Application : Sheet

Screw Design : Single-screw

Contact Now

Raw material: LDPE, GMS, TAC, Talc, Butane or Natural Gas

Sheet Width:1000-2000mm

Sheet thickness:1.0-10.0mm

Capacity:5T/day

Certification: CE, ISO9001

Skype:lewis15863824208

EPE Foam sheet Unit(FCFPM-150)

The line takes Butane as the vesicant, and adopts physical method to produce the high foaming sheet. The products can be used as the shock absorption and protection packing of the TV setes, refrigerators,bicycles, motorcycles and furnitures. After compounding with other materials, the products can be served as box bag lining, life jacket and swim-practising plate, it also application for as the heat preservation of plastics green house in winter and the many decoration materials with sound absorption and heat insulation in building.

Main Technical Parameters of EPE Foam Sheet Unit:
Model:		FCFPM-90	FCFPM-105		FCFPM- 120	FCFPM-150	FCFPM-170
Extruder:		90/55	105/55		120/55	150/55	170/55
Screw speed:	r/min	5-45
Foaming Ratio:		10-40
Product width:	mm	800-1600	1000-2000		1000-2000	1000-2000	1000-2000
Product thickness:	mm	0.5-3.0	0.5-5.0		0.8-8.0	1.0-10.0	2.0-15.0
Cooling Method		Air-cooled, water-cooled
Installed Power	kw	90	100	120		150	180
Dimension:	m	20×2.3×2.2	23×2.3×2.2	25×2.3×2.2		30×2.3×2.2	32×2.3×2.2
Weight:	T	6	8	12		15	17

Lewis here, please do not hesitate to contact with us, we will provide you the best solution for your investment!

You can know more EPE foam sheet transmission production machines from video link:

1.EPE Foam Sheet Extrusion Line Working flow:	http://www.youtube.com/watch?v=ibhaPWeYa54
2.EPE Foam Sheet Extrusion Line Working flow:	http://www.youtube.com/watch?v=Qmstlogf_FM

Main Technical Parameters of EPE Foam Sheet Extruder Line:
Model:		FCFPM-90	FCFPM-105		FCFPM- 120	FCFPM-150	FCFPM-170
Extruder:		90/55	105/55		120/55	150/55	170/55
Screw speed:	r/min	5-45
Foaming Ratio:		10-40
Product width:	mm	800-1600	1000-2000		1000-2000	1000-2000	1000-2000
Product thickness:	mm	0.5-3.0	0.5-5.0		0.8-8.0	1.0-10.0	2.0-15.0
Cooling Method		Air-cooled, water-cooled
Installed Power	kw	90	100	120		150	180
Dimension:	m	20×2.3×2.2	23×2.3×2.2	25×2.3×2.2		30×2.3×2.2	32×2.3×2.2
Weight:	T	6	8	12		15	17

Contact:	Mr Lewis
Email:	lewis@goodeggtraymachine-com.ecer.com
Skype:	lewis15863824208
Gtalk:	lewis15863824208@gmail.com
Yahoo Messenger:	lewis15863824208@yahoo.com
Mobile:	+86-15863824208
Website:	http://www.goodeggtraymachine-com.ecer.com
We are the professional manufacturer of Pulp moulding Machine and EPE Foam Extruder Line etc in Longkou ,Shandong Province, China.

EPE Foam sheet Unit(FCFPM-150) Images
